Product Description
Featuring a robust, environmentally sealed waterproof case, drive by wire throttle control, intake and exhaust cam control, short term and long term map learning, knock control, and much more, the Elite 1500 ECU provides engine calibrators the tools they need to get the job done right. Alongside the Elite 1500 ECU is the Elite Software Programmer (ESP) that brings levels of functionality and user friendliness never seen before in an engine control package. Together they offer true cutting edge technology to tuners and performance enthusiasts worldwide.
Features
- Drive by Wire Throttle Control (DBW)
- Low Impedance Injector control with programmable injector peak and hold currents and programmable peak time
- Flex fuel support (Direct sensor input). Tune your engine's boost, fuel and ignition by ethanol content
- Flexible tuning setup for Petrol (Gasoline), Methanol and Ethanol
- Closed Loop 02 Control. Dual bank control for precise tuning (with optional external CAN O2 Wideband Controller Kit)
- Knock Control. Synchronised to engine position with high speed digital filtering for accurate detection
- Variable cam control - Independently control up to 4 camshafts
- Closed Loop Idle Speed Control with learning for consistent idle stability
- Long term learning (auto tune) on fuel, ignition, cam, boost and idle control maps (up to 4D)
- On-board data logging. Up to 40 channels of logging at sample rates up to 5ms (200Hz) with 2MB of internal memory
- Laptop data logging. DLog all available channels directly to your laptop's hard drive for both tuning and diagnostics
- Dual CAN Bus communication for Haltech dashes and expansion devices. Supports OEM CAN and OBDII. View live engine data and set/clear diagnostic trouble codes
- 1 - 4 Injection stages with individual injector flow rates per injector
Benefits
- Anti-Lag/Rotational idle for closed course racing, rally, circuit or drift. Build and maintain boost during closed throttle conditions
- Rolling Anti-Lag. Lock to your current or pre-set RPM or road speed for roll racing or pit lane limiting
- Launch Control. Control your engine's power delivery, RPM and boost for consistent performance at the start line
- Traction Control. Control your engine's power output via mappable front vs rear axle or individual wheel speed slip
Please Note: Available with universal wiring, terminated engine harnesses or model-specific Plug'n'Play adaptor kits.
Applications
- Universal
What's In The Box?
- 1 - Elite 1500 ECU with DBW and Race Functions
- 1 - USB programming cable and USB Software Key
Warranty
- Haltech Limited Warranty
